Magazine Loader CE
Located at the first stage of an SMT line, magazine loader transfers PCBs stacked in a magazine rack to the downstream machine.
Previous image
Next image
Play Video
Description
Located at the first stage of SMT line, this unit transfers PCBs stacked in a magazine rack to the downstream machine using a pneumatic pusher one by one.
Features
- Touch screen (Operating panel)
- Tower lamp
- Manual width adjustment
- SMEMA interface
- Controlled by PLC
- Magazine slot - 50ea
- Pitch selection (1~4 pitch)
- Jam detection (Pneumatic)
- Exit guide
- Magazine capacity : upper 2 / lower 2
Options
- Auto width adjustment
- High speed magazine change
- Jam detection (Electric-torque)
- Width synchronization
- Line control
- ESD powder coating (RAL 7035)
